| Automatic comprehensive water processor | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Introduction
Prove through long-term practice, prevalent in today's water system fouling, corrosion, sludge, in the propagation of microorganisms such as the four major hazards. Water system, especially the water quality of the recycled water system is often integrated. Water treatment equipment used in the past due to the limitations of a single device function can not be resolved, so the need for further practical techniques to be addressed. Through the use of the combination of high-frequency technology and power field effect for electrochemical corrosion, fouling, the reproduction of bacteria and algae, using multi-band and high-voltage electrostatic combination, the design and manufacture of integrated water processor.
Working Principle
Integrated water processor first high-frequency technology, the role of high frequency electric force so that the water activation, water Ca2 of Mg2 ion velocity decreased, the effective number of collisions with the water of the CO32-in SO32-ion reduction, decreased electrostatic attraction,heated wall or pipe table and can not scale, so as to achieve the purpose of anti-scaling. High frequency electromagnetic field so that the force of penetration and solubility increases, the weak link in vertical penetration scale and the metal surface to the metal surface, along the lateral penetration of the metal and the scale surface scale flaky from the metal surface, so as to achieve the descaling purpose. Micro-environment of power can curb the growth of microorganisms, the destruction of their living environment, the addition of reactive oxygen species generated in the device process, with a role of damage biological macromolecules, changing the fungi, algae and the survival of biological field in order to achieve sterilization algicide purpose. The composite filter system (surface filtration principle followed by the composite layer of the multi-media, power field effect) adsorption, capture water iron and manganese ions of suspended matter, bacteria and algae colloid and removal system, the role of ultra-clean filter.
Technical parameter
(1)Control the corrosion rate: <0.01 mm / year, the filtration efficiency of> 75% ~ 98%, Anti-fouling efficiency> 95%, sterilization algae> 92%；
(2)Pressure loss: <0.03 ~ 0.06Mpa； (3)Operating voltage: AC 160V ~ 240V； (4) Security insulation voltage: 5000V； (5) Power consumption: <120W ~ 600W； (6)Working environment requirements: temperature from -25 ° C ~ +50 ° C Relative humidity <95%； (7)Operating temperature (processing medium temperature): -25 ℃ ~ +50° C；
(8)Average time between failures: not less than 50,000 hours；
Equipment processing
① In order to facilitate equipment installation and maintenance, the main top and the largest diameter is required with other equipment more than 400mm apart.
② Prohibited in the anhydrous state for a long time to turn the device on
③ The equipment should be the bypass installation, to meet the maintenance of equipment and anti-the need to rinse the filter body without stopping the machine state.
④ Sewage rate: the initial use of the new system, backwash 1 or 2 times daily. Normal operation, when the inlet and outlet pressure reaches 0.03 ~ 0.06Mpa backwash. Serious pollution of the system should be used in gas, mixed with water backwash.
⑤ Backwash: Open the trunk valve, drain valve, turn the device off the inlet valve, reverse flushing filter body. Backwash time varies depending on the water quality of the case may be, under normal circumstances, about 30 seconds.
⑥Resurrection out of the outlet pressure differential filter body back to the original pressure value, open the inlet valve, close the trunk valve, drain valve connected to 220V power supply device to work.  Scope of Application
① Central air conditioning, chiller, refrigerator; cooling, chilled circulating water system. Overall dimension Ⅰ type② Use systems: heating, heating, hot water circulation system. ③ Industrial,residential,cooling water:in the industrial,civil,process cooling circulationg water system. ④ Apartments,hotel:living bath,hot water circulation system,catering,laundry,swimming pool. ⑤ Geothermal water system:the use of geothermal water for bathing,heating circulation system.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
