Electronicmagnetic Descaler Water Treatment_Jiangsu YLD Water Processing Equipment Co.,Ltd.

Working principle

This kind of processor is designed based on the mechanism of water of different quality to be treated by different electromagnetic fields. The main engine generates electromagnetic field for water treatment. Under the condition of resonance, having been deeply broken, associative key of water in large association structure is dissociated into unimolecular with strong activity or water molecules in small association structure. As a result, the physical structure and properties of water are changed, specifically in stronger polarity of water molecules, larger dipole moment, and greater ability to hydrate components such as calcium and magnesium and carbanion that are easy to form scale, as well as to prevent scale formation. Meanwhile, under the condition of high-frequency electromagnetic field, original scale crystallization gradually becomes soft, falling off and dissolved, thus the purpose of scale removal is obtained.

Electronic-magnetic water treatment is widely used in construction, chemical, metallurgy, coal, rubber, light industry, pharmaceutical, food, refrigeration and other industries cooling water system, central air conditioning water system, hot water boiler water system, domestic water system, heat exchange system.

Specification

Model	Flow rate （T/h）	Inlet & outlet		D （mm）	L （mm）	Input power （W）	Net.Weight （Kg）
Model	Flow rate （T/h）	mm	in	D （mm）	L （mm）	Input power （W）	Net.Weight （Kg）
YL-0.5	1.8	15	0.5	159	500	25	35
YL-1	4.9	25	1	159	500	25	35
YL-1.5	12	40	1.5	159	500	25	35
YL-2	19	50	2	159	500	25	35
YL-2.5	28	65	2.5	159	500	25	40
YL-3	50	80	3	219	600	50	45
YL-4	80	100	4	219	600	50	50
YL-5	125	125	5	219	600	70	55
YL-6	180	150	6	273	600	70	65
YL-8	320	200	8	325	700	80	80
YL-10	490	250	10	377	700	120	90
YL-12	710	300	12	426	750	210	120
YL-14	1000	350	14	478	800	250	130
YL-16	1400	400	16	530	850	330	150
YL-18	1600	450	18	630	900	410	180
YL-20	1970	500	20	720	950	500	200
YL-24	2850	600	24	820	1000	660	260
YL-28	3880	700	28	920	1100	900	320

The above data is for reference only, subject to each shipment product data.
