Household water softener
◆ Working principle Water hardness is mainly calcium (Ca2 +), magnesium (Mg2 +) ions formed. When the raw water containing hardness ions within the resin layer through the softener, the water of the calcium (Ca2 +), magnesium (Mg2 +) ion exchange resin adsorption was also the quality of the release of other objects of sodium (Na2 +) ions. Outflow from the water softener in the water is softened to remove hardness ions. When the resin to absorb a certain amount of calcium (Ca2 +), magnesium (Mg2 +) ions, you must be regenerated. Regeneration of salt is salt water rinse tank in the resin layer, the hardness ions on the resin and then replace it, with the regeneration of waste water discharge tank, the resin to soften and restore the exchange capacity. Multi-valve automatic water softener system consists of multiple control diaphragm (hydraulic and pneumatic), multi-valve controller, the resin tank, salt containers. Control procedures were based on pre-set diaphragm to control the various hydraulic issued a directive to complete the breaking of each pathway to achieve the regeneration of all running processes. ◆ Scope of Application Widely used in various industrial and commercial demineralized water preparation, such as boiler feed water, recycled water to add water, add water, heating and air conditioning systems and various industrial process water. Processing hundreds of tons of water to thousands of tons ◆ Wall hung gas heating water boiler(special water dispenser)
