Auto self cleaning Waterproof UV sterilizer
  Be processed by equipment inlet water into the reactor, according to certain speed from the reaction chamber through, the microorganism of the water by the high strength UVC illuminate, microbial DNA, RNA internal structure are destroyed, can't be reproduced, and do not use any chemical drugs in the case, reach national inspection standard.
•Hospital, all kinds of laboratory water disinfection, and the high content to a causative agent wastewater disinfection
•Application water disinfection, including residents resident buildings, residential, office buildings, hotels, restaurants, tap water factory, etc
•Aquatic product processing purification disinfection, shellfish purification disinfection, fish processing purification disinfection,ect.
•Military camps, the water supply system
•Urban wastewater disinfection, maximum capacity can reach above 1 million tons per day
•Swimming pools, water other entertainment water disinfection
•Cooling water disinfection, including power plant, nuclear power plant cooling water, industrial production cooling water, the central air conditioning system cooling water
•Biological, chemical medicine, cosmetics production with cooling water
•Sea water, fresh water nursery, breeding (fish, eels, shrimp, abalone, shellfish, etc) water, total processing water can reach above 200000 tons per day
•Agricultural water disinfection, including water and irrigation, greenhouse,ect.
Function&Characteristics of products&advantage
1、Using photochemical reactions and optical physics processing technology
2、Kill a variety of 40 bacterium,virus and algae
3、Bacteria killing rate up to 99.9%
4、Automatic cleaning device,the user save worry
5、Removable cover reactor design,cleaning thoroughly
7、Leading UV strength monitoring and sound and light alarm device
8、The cylinder body material has 304 or 316L stainless steel materials to choose
9、One-piece controller,the LED display,equipped with complete operating system,and the material of the stainless steel
Function
On the water, reclaimed water and wastewater disinfection
Material
Cylinder body: 304, 316 L material can be chosen
Cleaning device: 304, 316 L material can be chosen
Part number
Disinfection water(T/H)
Power（W）
In-out water
(Nominal/inch)
System pressure Kg/cm2
Uv lamp fault alarm system
The reactor size (cm)          L x W x H
Control cabinet size(cm)
anchor screw   (cm)
shipping weight(Kg)
YLCn-005
0.3
16
1/2"
6
30×6×11


5
YLCn-008
1
25
1/2"
6
exist
47×6.3×11


10
YLCn-050
2
40
1"
6
exist
100×9×20
Φ8.9×25 (C×L)
69×4×Φ1
25
YLCn-150
6
80
1+1/4"
6
exist
100×11×23
69×4×Φ1
30
YLCn-200
8
120
1+1/2"
6
exist
100×15.9×30
Φ8.9×45 (C×L)
69×7×Φ1
35
YLCn-300
12
160
2"
6
exist
100×15.9×32
69×7×Φ1
40
YLC-050
2
40
DN25/1"
6
exist
100×8.9×30
25×30×12 (W×H×T)
60×4×Φ1
45
YLC-150
6
80
DN32/11/4"
6
exist
100×10.8×30
60×4×Φ1
50
YLC-200
8
120
DN40/11/2"
6
exist
100×15.9×40
60×7×Φ1
60
YLC-300
12
160
DN50/2"
6
exist
100×15.9×40
60×7×Φ1
70
YLC-360
15
200
DN65/21/2"
6
exist
100×15.9×40
50×78×25 (W×H×T)
60×7×Φ1
120
YLC-500
20
240
DN65/21/2"
6
exist
100×21.9×50
60×11×Φ1.2
130
YLC-600
25
280
DN80/3"
6
exist
100×21.9×50
60×11×Φ1.2
140
YLC-700
30
320
DN100/4"
6
exist
100×21.9×50
60×11×Φ1.2
150
YLC-1000
40
360
DN100/4"
6
exist
100×21.9×50
60×11×Φ1.2
160
YLC-1200
50
400
DN125/5"
6
exist
100×21.9×50
60×11×Φ1.2
180
YLC-1500
60
420
DN150/6"
6
exist
170×27.3×57
120×16×Φ1.4
210
YLC-2000
80
560
DN150/6"
6
exist
170×27.3×57
120×16×Φ1.4
220
YLC-2500
100
700
DN150/6"
6
exist
170×27.3×57
60×128×30
(W×H×T)
120×16×Φ1.4
275
YLC-3000
125
840
DN150/6"
6
exist
173×27.3×57
120×16×Φ1.4
300
YLC-4000
150
1120
DN200/8"
6
exist
173×32.5×65
120×20×Φ1.6
325
YLC-5000
200
1400
DN200/8"
6
exist
173×37.7×72
120×22×Φ1.6
350
YLC-7000
300
2100
DN250/10"
6
exist
175×42.6×80
120×24×Φ2.0
400
YLC-10K
400
2520
DN250/10"
6
exist
176×52.9×95
60×150×40
(W×H×T)
120×28×Φ2.2
475
YLC-15K
600
3080
DN300/12"
6
exist
176×78×110
120×32×Φ2.4
600
YLC-20K
800
3920
DN350/14"
6
exist
designated
designated
designated
YLC-25K
1000
4760
DN350/14"
6
exist
designated
designated
designated
NOTE:
1、Equipment power supply 220V / 50HZ, the ultraviolet lamp tube service life≥9000 hours
2、The technical parameter table providing the equipment is suitable for water purification water , d, isinfection, such as, : tap water, pure water, aquaculture water, food processing water, high quality water supply, medicine water etc.
3、Bactericidal efficiency depends on the transparency of the water body, impurity and, temperature, bactericidal efficiency is 99.9% or special design
4、YLCn model for thread interface, YLC model for flange constructed interface
5、According to the customer need to configure a variety of advanced on-line monitoring instrument and remote control system, such as: UV lamp control system, UV intensity monitoring system, the water temperature detection system, disinfection time accumulation system
6、According to the customer need to manually configure the type cleaning device or automatic cleaning device.
